Place of Origin:
China
Brand Name:
HYF
Certification:
ISO, SGS, etc.
Model Number:
HYF
85gsm Wet Stength Vacuum Metallized Paper For Can Label
1. Grammage & Usage
2. Process of Vacuum Metallized Paper
1) Coated base paper ;
2) Then metalizing 1-3gsm layer on the coated side
3) End coated on metallized layer
3. Features of Vacuum Metallized Paper
4. Technical Data Sheet Of Vacuum Metallized Paper
Number | Property | Unit | Test Method | Value | |
1 | Grammage | g/m2 | GB/T451.2 | ±3 | |
2 | Moisture | % | GB/T462 | 5.5±1 | |
3 | Wet Strength | MD | KN/m | GB/T465.2 | ≥1.0 |
TD | KN/m | GB/T465.2 | ≥0.7 | ||
4 | Tensile Strength | MD | KN/m | GB/T453 | ≥3.5 |
TD | KN/m | GB/T453 | ≥1.8 | ||
5 | Wet Tensile Strength | mN/m | GB/T14216 | ≥36 | |
6 | Break Load | MD | mN | GB/T455.1 | ≥350 |
TD | mN | GB/T455.1 | ≥350 | ||
7 |
Reverse Side COBB (60s)
|
g/m2 | GB/T1540 | 15±5 | |
8 |
Aluminum Firmness
|
% | _________ | ≥95 | |
9 | Alkali Resistance | S | _________ | ≤90 | |
10 | Gloss(45°) | % | GB/T8941.2 | EMBOSSED≥200 | |
_________ | _________ | PLAIN≥300 | |||
11 | Smoothness | S | GB/T456 | EMBOSSED≥600 | |
_________ | _________ | PLAIN≥1000 |
5. FAQ
Which paper and board bases are used for producing metallized materials at Golden Elephant?
We only use high quality raw materials of trusted manufacturers.
Wet strength paper: Stora Enso, Aralar;
LWC and Coated paper : Cham Paper Group,Gold East Paper ;
FBB&SBS Ivory board&Duplex Board:Ningbo APP and Sun Paper group Dragons paper .
What are the advantages and disadvantages of printing on the metallized surface of UV-curable inks?
Printing with UV inks is a more versatile and environmentally friendly method for non-absorbent materials. The advantage of this technology is that it requires no anti-set-off powder and the ink dries almost instantly.
However, UV inks are more expensive than foil ones and can be used only for special printing machines that feature extra driers. This makes the process more energy consuming and expensive when using the UV inks.
Do the HYF’s metallized materials require any preparation (priming) before printing?
No, they don’t, as the board and paper produced by Golden Elephant carry a finishing primer ensuring high-quality printing with UV and foil offset alkali proof inks.
Before printing, the material should be acclimatized in the production room for at least 2 hours. If the difference between the temperatures of the metal and the room is big, the acclimatization should be prolonged to 24 hours.
