Place of Origin:
China
Brand Name:
HYF
Certification:
ISO, SGS, etc.
Model Number:
HYF
Soft Shrinkable Packaging PET Heat Shrink Film For Label Printing
Product Information
PET or PETG shrink film, mainly for beverage sleeve label, tubing application, is excellent for shrink control, worldclass film flatness and high shrinkage. PET shrink sleeve film is combining high overall shrinkage and excellent printability. The favorable film toughness and shrinkage character combine to make a film suitable for a wide variety of container shapes.
Specifitations
| NO | ITEM | CHARACTERISTICS |
| 1 | Shrinkage |
60%~78% |
| 2 | Thickness | 20~80mic |
| 3 | Density | 1.35g/cm3 |
| 4 | Width | 250~2000mm |
| 5 | Transparency | Transparent |
Application
Full or partial body shrink sleeves;
Full or partial body roll sleeves;
Tamper-evident band;
Wine capsules and disk plates;
Pressure-sensitive shrink labels;
Promotion combining pack;
Sleeves for special-shape bottles of such as beverage,cosmetics,liquor and so on; and other application.
Technical Index of PET Shrink Film
| No | Test Item | UNIT | Standard | Test Result | Decide | |||
| 1 | (Average thickness deviation) | μm | ±3 | 0 | Qualified | |||
| 2 | TENSILE STRENGTH | (MD) | MPa | ≥42 | 65.8 | Qualified | ||
| (TD) | MPa | ≥142 | 231 | |||||
| 3 | ELONGATION | (MD) | % | ≥300 | 591 | Qualified | ||
| (TD) | % | ≥35 | 55 | |||||
| 4 | (Elasticity Modulus) | (MD) | MPa | ≥1500 | 3269 | Qualified | ||
| (TD) | MPa | ≥3000 | 7370 | |||||
| 5 | HEAT SHRINKAGE | (MD) | % | ≤5.0 | 2.3 | Qualified | ||
| (TD) | % | 60～70 | 66 | |||||
| 6 | (HAZE) | % | ≤7.0 | 2.2 | Qualified | |||
| 7 | C.O.F | (IN/OUT) | dynamic friction coefficient | / | ≤0.50 | 0.47 | Qualified | |
| 8 | WETTING TENSION | mN/m | ≥38 | ≥38 | Qualified | |||
| 9 | Density | g/cm3 | 1.32±0.3 | 1.46 | Qualified | |||
Advantages
1. High and stable shrinkage, suitable for all kinds of special bottle labels.
2. Eco-friendly.
3. High performance surface for enhanced printability allows multiple graphic scheme.
4. High-impact strength.
Our Service
FAQ:
Payment ( For initial cooperation, as to Shenghe company rules)
30% T/T in advance before production, balance paid before shipment.
Irrevocable L/C at sight
Delivery Time
Normally 20 days after confirmation of orders.
Special case in which you want us to finish products within 10 days, we can discuss details about this.
Logo
HYF label, customer label, or neutral label
MOQ
The MOQ is 1000 kgs. And we regularly produce this product for 30000 tons a month. If you want small testing quantity, like 500 kgs, you can discuss with us.
Welcome your question and inquiry.
