Product Details:
Payment & Shipping Terms:
|
| Material: | PETG Shrink Film | Transparency: | Transparent |
|---|---|---|---|
| Shrinkage Rate: | TD≈60-78%, MD≈0-5% | Width: | 200mm-1000mm |
| Thickness: | 20-50mic | Length: | Customized |
| High Light: | silicone coated film,plastic shrink film |
||
Soft Clear Transparency PET / PETG Shrink Film For Bottle Labelling And Packing
1. Product Details:
POLYESTER(PETG) considered as a kind of ester film met friendly environment is mainly used to pack
with PET containers or bottles, it can cut down recycling cost. PETG shrink film is availabel for
a variety of packaging types, sleeves, tamper evidence, extruded roll stock, shtink bags or cap seal
according to customers' size.
2. Advantages of PET / PETG Shrink Film Packing :
1) High and stable shrinkage, suitable for all kinds of special bottle labels;
2) Stable and good tensile strength;
3) Excellent gauge and shrinkage uniformity;
4) Good ink adhesion;
5) Advanced machining properties
3. Product Specifications:
1) Thickness: 35mic - 50mic
2) Width: 150mm - 1000mm
3) Length: 1000m - 5000m
4) The shrinkage: 60% - 78%
5) Can provide free samples of 150m - 200m.
4. Prodcut Parameters:
| No | Test Item | UNIT | Standard | Test Result | Decide | |||
| 1 | (Average thickness deviation) | μm | ±3 | 0 | Qualified | |||
| 2 | TENSILE STRENGTH | (MD) | MPa | ≥42 | 65.8 | Qualified | ||
| (TD) | MPa | ≥142 | 231 | |||||
| 3 | ELONGATION | (MD) | % | ≥300 | 591 | Qualified | ||
| (TD) | % | ≥35 | 55 | |||||
| 4 | (Elasticity Modulus) | (MD) | MPa | ≥1500 | 3269 | Qualified | ||
| (TD) | MPa | ≥3000 | 7370 | |||||
| 5 | HEAT SHRINKAGE | (MD) | % | ≤5.0 | 2.3 | Qualified | ||
| (TD) | % | 60～78 | 66 | |||||
| 6 | (HAZE) | % | ≤7.0 | 2.2 | Qualified | |||
| 7 | C.O.F | (IN/OUT) | dynamic friction coefficient | / | ≤0.50 | 0.47 | Qualified | |
| 8 | WETTING TENSION | mN/m | ≥38 | ≥38 | Qualified | |||
| 9 | Density | g/cm3 | 1.32±0.3 | 1.46 | Qualified | |||
5. FAQ:
1) Q: What is your MOQ?
A: Normally our MOQ for each size is 1ton. If you think it is too much, we can discuss according to your
requirement in details.
2) Q: Can you offer free sample?
A: Yes, we can provide free samples of 150m - 200m.
3) Q: What is your delivery time?
A: We deliver in 10-20days.
4) Q: Can you accept mixed products in one container?
A: Yes, we can.
6. Transportation:
1) Over the sea: The films are suggested to be shipped with reefer container. If less than container
loading, anti-heat material is advised to be used for packing to protect the films.
2) Container over the land: The truck with electronic power should be used for moving the container
between port and factory to keep the reefer container working.
7. Storage:
1) The film are suggested to be stored in the warehouse with temperature below 23℃, if in hot
season, installing air conditioner or other solution to cool down the warehouse shoud be taken.
2) The film storage period is 3 months. Please try to use up film within 3 months while they are at perfect
conditon.
