Place of Origin:
China
Brand Name:
HYF
Certification:
ISO, SGS, etc.
Model Number:
HYF
78% Printable Clear Heat Shrink PETG Film For Body Shrink Sleeves
1. Description
PETG – Polyproplyene Terephthalate Glycol (PETG) is an amorphous plastic resin of the polyster family. The Heat shrink film produced by PETG is a high density film with a high strength ratio and excellent clarity.Due to its 80% shrinkage, highest among all shrink sleeve material, PETG is an ideal solution for container shrink film that have complex geometries and require superior printability.
Compared to other material, PETG Shrink film is much more environmentally friendly making it a perfect solution for companies looking to switch from more harmful materials such as PVC. The heat shrink film could be used to pack with PET containers or bottles, provided that can cut down recycling cost. Since PETG’s shrinkage occurs at a lower temperature than material like PVC and OPS, there is the added benefit of higher energy efficiency and productivity.
2. Technical Data Sheet
| No | Test Item | UNIT | Standard | Test Result | Decide | |||
| 1 | (Average thickness deviation) | μm | ±3 | 0 | Qualified | |||
| 2 | TENSILE STRENGTH | (MD) | MPa | ≥42 | 65.8 | Qualified | ||
| (TD) | MPa | ≥142 | 231 | |||||
| 3 | ELONGATION | (MD) | % | ≥300 | 591 | Qualified | ||
| (TD) | % | ≥35 | 55 | |||||
| 4 | (Elasticity Modulus) | (MD) | MPa | ≥1500 | 3269 | Qualified | ||
| (TD) | MPa | ≥3000 | 7370 | |||||
| 5 | HEAT SHRINKAGE | (MD) | % | ≤5.0 | 2.3 | Qualified | ||
| (TD) | % | 60～78 | 66 | |||||
| 6 | (HAZE) | % | ≤7.0 | 2.2 | Qualified | |||
| 7 | C.O.F | (IN/OUT) | dynamic friction coefficient | / | ≤0.50 | 0.47 | Qualified | |
| 8 | WETTING TENSION | mN/m | ≥38 | ≥38 | Qualified | |||
| 9 | Density | g/cm3 | 1.32±0.3 | 1.46 | Qualified | |||
3. Features
1) PET/PETG shrink wrap film is the environmentally friendly material for package.
2) This product is seamless tube of PET/PETG shrink film.
3) High clarity and excellent shrinkability.
4) Can be made dome bag and cut band
4. Advantages
1) Excellent printability
A) Reverse prints with stunning clarity, gloss and presence.
B) Surface printed with existing technology and without special pretreatment.
2) All-encompassing design
A) Ability to wrap around container with 360 degree graphics
B) Front or reverse surface printing brings out the best in colors and graphic design
3) Crystal Clarity
A) Water-like clarity showcases colors and graphics
4) High shrink rate
A) Flushes beautifully against complex contoured surfaces and tight fit remains over time.
B) Reaches maximum shrinkage potential more quickly than competitive products(up to 80% ultimate shrinkage)
C) Higher shrinkage reached at lower temperatures-great for heat sensitive products
5) Halogen-free*
A) Unlike PVC, It is Halogen-free shrink film material.
6) Machine runnability
A) High tensile strength
B) Low coefficient of friction
7) Lower carbon foot print
A) Recycled with PET bottles
B) Halogen free unlike PVC
7. Transportation:
1) Over the sea: The films are suggested to be shipped with reefer container. If less than container
loading, anti-heat material is advised to be used for packing to protect the films.
2) Container over the land: The truck with electronic power should be used for moving the container
between port and factory to keep the reefer container working.
8. Storage:
1) The film are suggested to be stored in the warehouse with temperature below 23℃, if in hot
season, installing air conditioner or other solution to cool down the warehouse shoud be taken.
2) The film storage period is 3 months. Please try to use up film within 3 months while they are at perfect
conditon.
