450mm Heat Shrink Film Roll

450mm Heat Shrink Film Roll
450mm Heat Shrink Film Roll

Large Image :  450mm Heat Shrink Film Roll

Product Details:
Place of Origin: China
Brand Name: HYF
Certification: ISO, SGS, etc.
Model Number: HYF
Payment & Shipping Terms:
Minimum Order Quantity: 1000KG
Price: Negotiation
Packaging Details: Standard Export Package
Delivery Time: 15-20 Work Days
Payment Terms: L/C, T/T, Western Union, PayPal
Supply Ability: 3,000 Tons/Month
Detailed Product Description
Name: Clear Polyester Film Feature: Soft
Transparency: Clear Hardness: Soft
Width: 200mm-1000mm Thinckness: 30mm-50mm
Sample: Available Other Name: Heat Shrink Film Label
High Light:

silicone coated film

,

plastic shrink film

OEM Soft Clear Polyester Film / Low Through Heat Shrink Film Label



Clear Polyester Film Details:



Clear Polyester Film mainly for beverage sleeve label, tubing application is excellent for shrink control and worldclass film flatness, high shrinkage. PET shrink sleeve film is combining high overall shrinkage and excellent printability. The favorable film toughness and shrinkage character combine to make a film suitable for a wide variety of container shapes. The film thickness is from 35-45mic, TD Shrinkage from 60-70%.



Clear Polyester Film Specifications


1) Thickness: 20mic - 80mic
2) Width: 450mm - 1000mm
3) Length: 3000m - 6000m
4) The shrinkage: 70% - 78%



Clear Polyester Film Parameters



Item Unit Typical Value Testing Method
Thickness mic 40, 45, 50, 60 ASTM D374
Thickness Tolerance % ±3
Material Yield m²/kg
40mic 18.9
45mic 16.8
50mic 15.2
60mic 12.6
Tensile Strength MD Mpa 50 ASTM D882
v=100mm/min
TD 240
E-Modulus MD 1900
TD 4300
Elogation At Break MD % 430
TD 39
Heat Shrinkage MD % 0 ASTM D 1204
90℃/10Sec/Water
TD 78
C.O.F us 0.485 ASTM D1894 E
uk 0.43
Haze % 3.65 ASTM D1003
Gloss(45°) 110 ASTM D2457
Dyne mN/m 40 ASTM D2578
Density g/cm³ 1.32 ASTM D792



Clear Polyester Film Application


1) Widely for all types of bottles, cups, trays printing.
2) Used for making full body sleeves and containers.



450mm Heat Shrink Film Roll 0

Advantages Of Shrinkable Polyester Films


PETG is an amorphous plastic resign of the polyester family. Due to its high shrinkage, highest among all shrink sleeve material, PETG is an ideal solution for container shrink film that has complex geometries and requires superior printability. Compared to other material, PETG resign is much more environmentally friendly making it a perfect solution for companies looking to switch from more harmful materials.


FAQ



1) Q: Can I have a sample order?
     A: Yes, we welcome sample order to test and check quality.
          Mixed samples are acceptable.


2) Q: What is the lead time?
     A: Sample needs about 7 days prepared; mass production time needs 15-25 days          normally.



3) Q: Do you have any MOQ limit?
     A: Our MOQ is 1Tons.


4) Q: Where is your Sea Port?
     A: FOB Shanghai.


5) Q: What information should I let you know if I want to get a quotation?
     A: The external size of your products (Thick x Width x Length) The quantity.
